PVC pipe Application PVC pipe Specifications Advantages of PVC pipe

PVC pipe Application

Application

Urban tap water supply and water supply project
Building internal and external water supply project
Industrial and mining enterprise water supply project
Underground fire water supply project
Farmland water conservancy water supply irrigation project
Gardening and gardening green water supply project
Aquaculture water supply and drainage project, etc.

PVC pipe Specifications

Size	Size	Diameter	Socket Depth (mm)	Wall Thickness
mm	Inch	Tolerance (mm)		Wall Thickness
DN	DN	Tolerance (mm)		W. T.	kgs/m
20	1/2”	0.2		1.7	0.152
25	3/4”	0.2		1.7	0.194
32	1”	0.2		1.8	0.266
40	1 1/4”	0.2		2.0	0.373
50	1 1/2”	0.2	75	2.4	0.560
63	2”	0.3	100	3.0	0.888
75	2 1/2”	0.3	110	3.6	1.260
90	3”	0.3	120	4.3	1.806
110	4”	0.4	120	4.2	2.178
125	5”	0.4	119	4.8	2.828
140	5 1/2”	0.5	125	5.4	3.563
160	6”	0.5	132	6.2	4.674
180	6”	0.6	145	6.9	5.854
200	8”	0.6	145	7.7	7.258
225	8”	0.7	152	8.6	9.122
250	10”	0.8	160	9.6	11.312
280	10”	0.9	170	10.7	14.124
315	12”	1	180	12.1	17.965
355	14”	1.1	180	13.6	22.758

Advantages of PVC pipe

Light weight, easy to transport, unload and install.

Low flow resistance, low wall friction coefficient, which is 0.009, low flow resistance and strong conveying capacity.

Low system cost and low maintenance cost can greatly reduce project costs.s

Non-excavation installation

a variety of non-excavation methods can be adopted to facilitate construction and installation.

Environment friendly

the material is PVC resin, sanitary, pollution- free, clean and cheap.

Corrosion resistance

PVC pipelines are resistant to corrosion by a variety of chemical media, and chemicals present in the soil do not cause any degradation to the pipeline.

No leakage

The PVC pipe system is connected by glue connect, rubber ring joint, flange connect methods, which have the good sealing performance when using.

High mechanical resistance

PVC pipes have good compression resistance, impact resistance and tensile strength.

Long service life

The buried PVC pipe is normally used for 70 years.

Recyclable, environmentally friendly

PVC materials can be reused, fully in line with the nationally advocated efficient environmental protection concept.
